ServerNet node routing ID
number is assigned based on the port to which the node is connected on the cluster
switch. The ServerNet node number, which can be viewed using the Subsystem
Control Facility (SCF), the OSM Service Connection, or the TSM Service Application,
is unique for each node in a ServerNet cluster.
ServerNet node routing ID. A bit field used to route ServerNet packets across the external
ServerNet X and Y fabrics. The ServerNet node routing ID occupies the upper six bits
of the 20-bit ServerNet ID, and it is unique for each member, or node, in a ServerNet
cluster. This term is the fully qualified form of
node routing ID.
SERVERNET object type. In the Kernel subsystem, the object type for either the $ZSNET
ServerNet subsystem manager process or the ServerNet X fabric or Y fabric.
ServerNet packet. The unit of transmission in a ServerNet communications network. A
ServerNet packet consists of a header, a variable-size data field, and a 32-bit cyclic
redundancy check (CRC) checksum covering the entire packet. The header contains
fields for control, virtual memory address, and destination and source fields to identify
the processor or I/O controller transmitting and receiving the packet. See also request
packet and response packet.
ServerNet port. A connector used for ServerNet links. Six ServerNet ports are located on a
ServerNet expansion board (SEB). Ten ServerNet ports are located on a modular
ServerNet expansion board (MSEB).
ServerNet router. An application-specific integrated circuit (ASIC) responsible for routing
ServerNet packets along ServerNet links in the ServerNet fabrics, using routing
information that is present within the packets. A ServerNet router acts as a fully duplex
crossbar switch, able to switch any of its input ports to any of its output ports. A
ServerNet router in an HP NonStop™ S-series server has either six router ports (see
ServerNet router 1
) or twelve router ports (see ServerNet router 2).
ServerNet router 1. A model of ServerNet router that, in an HP NonStop™ S-series server,
has a total of six input and six output ports. See also ServerNet router 2
.
ServerNet router 2. A model of ServerNet router that, in an HP NonStop™ S-series server,
has a total of twelve input and twelve output ports. See also ServerNet router 1
.
ServerNet subdevice. An I/O device that sends and receives its information through a
controlling device that acts as the ServerNet device for routing purposes.
ServerNet subdevice ID. The low-order (least significant) bits of a ServerNet ID, used by a
ServerNet device to distribute incoming and outgoing information between itself and its
associated subdevices.
ServerNet switch. A point-to-point networking device that connects ServerNet nodes to a
single fabric (X or Y) of the ServerNet communications network. The ServerNet switch
routes ServerNet packets among these nodes.
