P
PMB
LMUs 4-39
memory slots 4-39
physical description 4-38
PMCU
appearance side 4-8
fan connections 4-12
FRU type 1-29
functions 4-8
service processors 4-8
slots 4-8
PMF 2 CRU
See also PMF CRU
faceplate 4-36
part numbers A-3
ports 4-37
ServerNet Router 2 4-49
PMF CRU
16 GB processor configuration
requirements 4-25
AC power 4-37, 4-56
communication pathways 6-2
configuration form, completing 13-16
faceplate 4-33, 4-34, 4-35
functions 4-49
LEDs 4-33
memory units
See Memory units
part numbers A-3
ports 4-37
power interlock 4-37
power supply configuration 12-9, B-11
ServerNet router 1 4-48
service class 1-28
topics 4-32/4-48
Point-to-Point Protocol (PPP) 1-45
Port Access Method (PAM) subsystem E-5
Post-installation tasks, new system,
overview of 9-7
Power distribution unit 4-71
Power factor correction (PFC) 12-8
Power failures, system behavior
during 10-6
/10-7
Power interface board (PIB) 1-29, 4-15
Power interlock 4-37, 4-56
Power loss, memory maintenance
during 10-6
Power monitor and control unit (PMCU)
See PMCU
Power outlets
convenience receptacles 12-7
labeling 12-7
Power requirements
branch circuits 12-8
earth grounding 12-6
isolation transformer 12-6
local regulations 12-6
Power shelf
front panel 1-26
, 4-59
power components 4-15
service class 1-30
type of enclosure with 1-6, 4-14
Power supplies 4-71
Power supply
in a power shelf
part number A-3
service class 1-26
slot locations 4-15
Powering on the system 7-1, 7-10
Power-fail delay time 10-6
configuring 10-7
Low Power Mode 10-6
maximum
calculated 10-6
, 10-7
configured 10-6
configuring 10-7
default 10-7
minimum 10-6
operational considerations 10-7
short power failures 10-6
