Expanding a System Online
HP NonStop S-Series System Expansion and Reduction Guide—522465-009
6-18
10. Verify Connection Between System Console and
Enclosure
10. Verify Connection Between System
Console and Enclosure
In this step, you check whether the system console and enclosure you have connected
are communicating.
10.1 Verify Connection to ServerNet X Fabric
Open a Command Prompt window on the system console and enter the following
command using the low-level link IP address of group 01, slot 50, from Worksheet 2.1:
C:\>ping IP-address-of-the-SP-in-slot-50
The following example is the display you see if the system console is connected to the
ServerNet X fabric:
If you receive any other messages, see Ping Command Does Not Work on page 7-7.
10.2 Verify Connection to ServerNet Y Fabric
Enter the following command with the low-level link IP address of group 01, slot 55,
from Worksheet 2.1:
C:\>ping IP-address-of-the-SP-in-slot-55
The following example is the display you see if the system console is connected to the
ServerNet Y fabric:
If you receive any other messages, see Ping Command Does Not Work on page 7-7.
C:\>ping 192.231.36.2
Pinging 192.231.36.2 with 32 bytes of data:
Reply from 192.231.36.2: bytes = 32 time = 10ms TTL = 60
Reply from 192.231.36.2: bytes = 32 time = 30ms TTL = 60
Reply from 192.231.36.2: bytes = 32 time = <10ms TTL = 60
Reply from 192.231.36.2: bytes = 32 time = 30ms TTL = 60
C:\>ping 192.231.36.3
Pinging 192.231.36.3 with 32 bytes of data:
Reply from 192.231.36.3: bytes = 32 time = 60ms TTL = 60
Reply from 192.231.36.3: bytes = 32 time = 11ms TTL = 60
Reply from 192.231.36.3: bytes = 32 time = 40ms TTL = 60
Reply from 192.231.36.3: bytes = 32 time = <10ms TTL = 60
