Expanding a System Online
HP NonStop S-Series System Expansion and Reduction Guide—522465-009
6-23
15. Power Off Enclosure
This possibility of recabling and reconfiguring means that you must pay careful
attention to Worksheets 3 and 4 for the Tetra 8 topology or Worksheets 5 and 6 for the
Tetra 16 topology.
15. Power Off Enclosure
You must power off the enclosure before connecting it to the target system.
16. Repeat Steps 6 Through 15 If Necessary
Skip this step if you are creating a block that contains only one enclosure:
Configure each enclosure separately before you assemble them into a block. This
practice greatly reduces troubleshooting.
If you need to move the system console between enclosures, see Move the System
Console on page A-8.
To prepare each enclosure for configuration into a block:
Step Action Result
1. From the OSM or TSM Low-Level Link, select the
Display menu.
A menu appears.
2. Select Actions. A menu appears.
3. Select Power Off.
4. Click Perform action.
5. Click OK.
6. Verify that the enclosure is powered off.
If You Are Creating … Then …
A block containing only one enclosure Skip this step. Go to Step 18. Change Group
Numbers of Block to Fit Target System on
page 6-27.
A block containing more than one enclosure Perform this step.
Step
Page (page 1
of 2)
6. Finish Gathering Information
6-14
7. Connect a System Console to the Enclosure 6-15
8. Change Group Number of Enclosure to 01 6-16
9. Power On Enclosure 6-17
10. Verify Connection Between System Console and Enclosure 6-18
11. Configure System Console and Enclosure 6-19
12. Verify SP Firmware Is Compatible 6-20
