17.2 Verify ServerNet Cabling
4. Connect the system console to the block. You performed these procedures for
each of the enclosures you have prepared. Now you perform these procedures for
the entire block.
17.2 Verify ServerNet Cabling
To be sure that enclosures within the block are cabled correctly, verify the ServerNet
cabling by performing this step for each PMF CRU and IOMF CRU in the block:
17.3 Power Off Block
Power off the block, as described in 15. Power Off Enclosure on page 6-23.
Step Page
7. Connect a System Console to the Enclosure
6-15
9. Power On Enclosure 6-17
Start the OSM or TSM Low-Level Link A-9
10. Verify Connection Between System Console and Enclosure 6-18
Step Action Result
1. From the OSM or TSM
Low-Level Link, select the
Display menu and click SP
Actions.
The Service Processor Actions dialog box
appears.
2. From the Service Processor (SPs) list, select an SP for an enclosure in the block
you are adding.
3. From the Actions list, select SP Responsive Test.
4. Click Perform action. When the action is completed, the status is
listed as Completed in the Action Status box.
5. Repeat this procedure from Step 2 for the other PMF CRU or IOMF CRU in the
enclosure.
6. Repeat this procedure from Step 2 for every other enclosure in the block you are
adding.
Note. For IOAM enclosures, your service provider must verify the ServerNet cabling by using
the ME Responsive Test of the OSM Low-Level Link Application.
