21.2 Connect ServerNet Cables Between Block and
Target System
21.2 Connect ServerNet Cables Between Block and Target
System
All ServerNet cabling connections appear in Appendix B, ServerNet Cabling, and on
Worksheets 3, 4, 5, and 6 in Appendix C.
You might have to recable the block from the configuration you gave it in Step
17. Assemble Enclosures Into a Block on page 6-24. Whether you must recable
depends on:
•
The topology of your target system
•
Where you are adding this enclosure in that topology
An enclosure probably must be recabled or reconfigured if you add it to a Tetra 16
topology as any group in the sequence 05 through 08 or 51 through 89.
When you attach the ServerNet cables, tighten the jack screws at either end.
21.3 Connect Power-On Cables Between Block and Target
System
Caution. When you attach the block to the target system, you must attach all ServerNet
cables correctly the first time.
For Information About See
Cabling patterns NonStop S-Series Hardware Installation and
FastPath Guide
