23a. Update Firmware and Code in Block (Using
TSM)
b. Click Perform action. The Update Action Summary
dialog box appears.
c. When the Status line lists the action as
Completed, click Close.
The Update Action Summary
dialog box disappears.
6. Examine the State Box for the SP Firmware.
•
Skip to Step 15 if both of the following conditions are true:
•
The state box is OK
•
You performed 13. Update SP Firmware in Enclosure If Necessary.
•
Otherwise, perform Step 6a through Step 6c:
a. Click the check box for the SP Firmware.
b. Click Perform action. The Update Action Summary
dialog box appears.
c. When the Status line lists the action as
Completed, click Close.
The Update Action Summary
dialog box disappears.
7. Click Cancel. The Single SP Firmware
Update dialog box disappears.
8. In the Physical view, double-click the processor
enclosure for the block you just added.
The Physical view displays
components on both sides of
the enclosure.
9. Right-click the slot for the SP you just updated. A menu appears.
10. Select Actions. The Actions dialog box
appears.
11. From the Select Component box, select Service
Processor.
Choices appear in the Actions
for list.
12. In the Actions for list, select Reset.
13. Click Perform action. After one to three minutes, the
Action Status box indicates a
successful Reset.
14. When the status line lists the action as Completed, click Close.
If the status line never lists the action as Completed, see the TSM documentation.
15. For the PMF CRU in slot 55 of the enclosure you added, repeat this procedure from
Step 3.
16. If you added any other enclosures, repeat this procedure for each enclosure from
Step 1.
Step Action Result
