Expanding a System Online
HP NonStop S-Series System Expansion and Reduction Guide—522465-009
6-35
23b. Update Firmware and Code in Block (Using
OSM)
23b. Update Firmware and Code in Block
(Using OSM)
Do this step even if you performed 13. Update SP Firmware in Enclosure If Necessary.
For each PMF CRU or IOMF CRU in each enclosure you added, check (and update if
necessary) the SP firmware, processor boot code, and SCSI boot code:
Note. For IOAM enclosures, your service provider must verify that the ME firmware and the
ME FPGA is the latest version. Updating the ME firmware and ME FPGA is described in the
Modular I/O Installation and Configuration Guide.
Step Action Result
1. In the OSM Service Connection, from the
Display menu, select Multi-Resource Actions.
The Multi-Resource Actions
dialog box appears.
2. From the Resource Type drop-down list, select
SP.
3. Select Processor Boot Millicode Firmware
Update from the Action drop-down list.
4. In the list of SPs, scroll to find the Processor Boot Millicode Firmware attributes and
compare the Version attribute to the Default File Version.
•
If the Version is older than the Default File Version, the Version is down-rev
and should be updated. Perform Steps 4a through 4e.
•
If the Version is the same as or newer than the Default File Version, skip to
Step 5.
a. Select the SP you need to update and click Add. The SP moves to the lower list.
b. Click Perform Action. After a confirmation dialog, a
Parameter Input dialog box
allows you to specify an
alternate file location for the
version to use for the update.
c. Enter a location or leave it blank if you are using
the default location, and click OK to perform the
update.
The Progress bar at the bottom
of the Multi-Resource Actions
dialog box indicates the pass or
fail status of the action.
d. When the action completes, check the Processor
Boot Millicode Firmware attributes again to
confirm that the Version now matches the
Default File Version.
If the action fails, click Action Summary and
then Details to get more information about why
the action failed.
e.
Perform a hard reset of the processor (do not
close the OSM Service Connection session or the
Multi-Resource Actions dialog box; you will use it
again in Step 5):
