Expanding a System Online
HP NonStop S-Series System Expansion and Reduction Guide—522465-009
6-36
23b. Update Firmware and Code in Block (Using
OSM)
1. Launch and log on to the OSM Low-Level
Link.
2. Click Processor Status. The Processor Status dialog
box appears.
3. Click to select the processor you want to
update.
4. From the Processor Actions list, select Hard
Reset and then click Perform action.
After one to three minutes, the
Action Status box indicates a
successful Hard Reset.
5. When the status line lists the action as Completed, click Close.
If the action does not complete successfully, see Action Detail for more
information.
5. Return to the Multi-Resource Actions dialog box. Select SCSI Boot Code Firmware
Update from the Action drop-down list.
6. Check the SCSI Boot Code Firmware attributes for the same SP and compare the
Version attribute to the Default File Version.
•
If the Version is older than the Default File Version, the Version is down-rev
and should be updated. Perform Steps 6a through 6e.
•
If the Version is the same as or newer than the Default File Version, skip to
Step 7.
a. If the SP you want to update is not already in the
lower list, select the SP and click Add to move it
to the lower list.
The SP moves to the lower list.
b. Click Perform Action. After a confirmation dialog, a
Parameter Input dialog box
allows you to specify an
alternate file location for the
version to use for the update.
c. Enter a location or leave it blank if you are using
the default location, and click OK to perform the
update.
The Progress bar at the bottom
of the Multi-Resource Actions
dialog box indicates the pass or
fail status of the action.
d. When the action completes, check the Processor
Boot Millicode Firmware attributes again to
confirm that the Version now matches the
Default File Version.
If the action fails, click Action Summary and
then Details to get more information about why
the action failed.
7. For the PMF CRU in slot 55 of the enclosure you
added, repeat this procedure from Step 3.
8. If you added any other enclosures, repeat this
procedure for each enclosure from Step 1.
Step Action Result
