Expanding a System Online
HP NonStop S-Series System Expansion and Reduction Guide—522465-009
6-38
25. Verify Operations in Added Block
25. Verify Operations in Added Block
This step ensures that all enclosures in the added block are operating normally:
26. Configure CRUs in Added Block
Now that you have connected the added block to the target system, you must
configure the CRUs in each enclosure of that block.
Finish configuring all the CRUs in one enclosure before moving to the next enclosure
in the block. Configuring CRUs one enclosure at a time minimizes variables in
troubleshooting.
How you configure your CRUs depends on your system and subsystems. System-
specific and subsystem-specific configuration information appears in the manuals
devoted to those systems and subsystems.
Step Action Result
1. Log on to the OSM Service
Connection or TSM
Service Application.
The Management window appears.
2. In the tree pane, click the
appropriate icons to view
each enclosure in the
added block.
All added enclosures and their components should
be displayed. The display might take several minutes
to finish.
If all added enclosures with their components do not
become visible after several minutes, see System
Discovery Does Not Show All CRUs or Enclosures on
page 7-13.
3. If any warning triangles or other signs of abnormality are displayed, diagnose and
solve the problems. See the OSM or TSM online help.
