Troubleshooting
HP NonStop S-Series System Expansion and Reduction Guide—522465-009
7-5
Amber LEDs Remain Lit
Amber LEDs Remain Lit
Green LEDs should remain lit on powered-on enclosures. However, if an amber LED
remains lit, see POST Fails on page 7-9.
Neither CRU Starts
See Added Enclosure Is Not Recognized by the Target System on page 7-4.
Cannot See Enclosure in OSM or TSM
See Added Enclosure Is Not Recognized by the Target System on page 7-4.
Configuration File Already Exists
When you are updating the system configuration database during one of these steps:
•
9. Finish the Reduction on page 4-19
•
1. Prepare Target System for Expansion on page 6-4
•
3. Prepare Target System for Addition of Block on page 6-9
you get this message:
Configuration file $SYSTEM.ZSYSCONF.CONFxxyy already exists.
Replace it? (Y/[N])
Cause
You requested that SCF save the configuration file with a name that already exists. If
you answer Y, you overwrite that existing system configuration database.
Recovery
Enter N and retry the SAVE CONFIGURATION xx.yy command with another value
for xx.yy.
