Troubleshooting
HP NonStop S-Series System Expansion and Reduction Guide—522465-009
7-9
POST Fails
POST Fails
The power-on self-test (POST) fails for one or more PMF CRUs or IOMF CRUs. This
situation might occur when you perform these steps:
•
9. Power On Enclosure on page 6-17
•
20. Power On Added Block on page 6-28
•
22.2 Check Configuration of All CRUs on page 6-32.
Symptoms of POST failure include:
•
The amber LED on the CRU remains lit for more than five minutes after the POST
finishes
•
SP event 602 (ZSPR-EVT-CRU-POST-FAILED)
•
Storage event 1033 (ZSTO-EVT-CRU-INIT-FAILED) in the $ZLOG service log
•
Storage event 1035 (POST of the CRU failed)
Symptoms of a successful POST include:
•
SP event 601 (ZSPR-EVT-CRU-POST-SUCCEEDED)
•
Storage event 1032 (ZSTO-EVT-CRU-INIT)
•
Storage event 1034 (POST of the CRU succeeded)
Cause
A CRU has failed.
Recovery
Contact your service provider.
Note. When POST fails before the added block is connected to the target system, the LEDs
are available but not the event messages.
