About This Guide
This guide describes how to expand or reduce a NonStop S-series system by adding
or removing enclosures.
This guide does not describe operations information for ServerNet clusters. For
information regarding the installation, configuration, and management of HP NonStop
ServerNet cluster hardware and software, see the ServerNet Cluster Manual and the
ServerNet Cluster 6780 Planning and Installation Guide.
Who Should Read This Guide
This guide is written for customers and service providers preparing to increase or
reduce the number of enclosures in a NonStop S-series system.
Topic Page
Who Should Read This Guide
xi
Section Abstracts xii
Where to Get More Information xiii
Manuals xiii
CSSI Web xiii
Notation Conventions xv
Notation Conventions xv
Notation Conventions xv
Hypertext Links xv
General Syntax Notation xv
Notation for Messages xvi
Change Bar Notation xvi
