Troubleshooting
HP NonStop S-Series System Expansion and Reduction Guide—522465-009
7-10
RELOAD Command Does Not Work
RELOAD Command Does Not Work
Not all processors in the system come up in response to a TACL RELOAD command,
as might happen during Step Skip this step if the added block does not contain a
processor enclosure. on page 6-37.
Cause
The ServerNet X fabric might be down.
Recovery
1. Enter this command and check for any status other than UP.
> SCF STATUS SERVERNET $ZSNET
2. Start any down fabrics:
> SCF START SERVERNET $ZSNET.X.*
> SCF START SERVERNET $ZSNET.Y.*
3. Return to Step Skip this step if the added block does not contain a processor
enclosure. on page 6-37.
If the problem persists, contact your service provider.
Request Timed Out
See Ping Command Does Not Work on page 7-7.
ServerNet Fabrics Are Cross-Cabled
Among the symptoms of this problem is an inability to see the enclosure in the OSM or
TSM Low-Level Link.
Cause
You attached one or more X fabric ServerNet cables to the Y fabric or vice versa. This
miscabling might have occurred during either of the following steps:
•
Connecting the cables wrong in 21.2 Connect ServerNet Cables Between Block
and Target System on page 6-30
•
Labeling the cables wrong in Step 5 on page 6-5
