Troubleshooting
HP NonStop S-Series System Expansion and Reduction Guide—522465-009
7-11
ServerNet Fabrics Are Down
Recovery
1. Disconnect ServerNet cables between the target system and the affected block.
2. Unplug the AC power cords of the affected block.
3. Unplug the battery packs in the affected block.
4. Replug battery packs in the affected block.
5. Begin the resizing process again at 20. Power On Added Block on page 6-28.
ServerNet Fabrics Are Down
One or more ServerNet fabrics might be down.
Cause
This can happen either:
•
On a system running a RVU earlier than G06.04
•
If a fabric was brought down manually
Recovery
1. Enter the following command and check for any status other than UP.
> SCF STATUS SERVERNET $ZSNET
2. Start any down fabrics:
> SCF START SERVERNET $ZSNET.X.*
> SCF START SERVERNET $ZSNET.Y.*
3. Return to Step 3.2 Eliminate Problems in the ServerNet Fabrics on page 4-6.
If the problem persists, contact your service provider.
Slots 50 and 55 Remain Unlisted for an Enclosure
After you connect the block to the target system, an SCF STATUS ADAPTER
command does not list slots 50 and 55 for one or more enclosures in the block.
Cause and Recovery
See Added Enclosure Is Not Recognized by the Target System on page 7-4.
