Troubleshooting
HP NonStop S-Series System Expansion and Reduction Guide—522465-009
7-12
Code 316 Returned During Logon
Code 316 Returned During Logon
While trying to log on to the OSM or TSM Low-Level Link during Step 12.1 Determine
SP Firmware Version for Enclosure on page 6-20, you get a code 316 error message
on the status bar at the bottom of the OSM or TSM window.
Cause
You are trying to configure an enclosure or block before adding it to a target system,
but the system console does not recognize the enclosure you are trying to configure
because you are connected to a group other than group 01.
Recovery
1. Unplug the AC power cords of the affected block or enclosure.
2. Unplug the battery packs from the power monitor and control unit (PMCU) in the
affected block or enclosure.
3. Replug battery packs into the PMCU in the affected block or enclosure, but do not
plug in the AC power cords yet.
4. Return to Step 8. Change Group Number of Enclosure to 01 on page 6-16.
Perform this step and all subsequent steps again.
Startup TACL Window Does Not Open
You cannot open a startup TACL window using the procedure Start a Startup TACL
Session on page A-9.
Cause and Recovery
If the preceding recovery procedures do not work, contact your service provider.
Cause Recovery
1. You get a “duplicate CLCI request”
message, indicating that a startup TACL
window is already open.
This message also gives you the IP
address of the workstation that currently
owns the startup TACL, from which you
can find the workstation.
2. The startup TACL window has no TACL
prompt because you attempted to open
a startup TACL window on the wrong
ServerNet fabric.
This is the backup fabric window.
Minimize it to see the primary fabric
window.
