Troubleshooting
HP NonStop S-Series System Expansion and Reduction Guide—522465-009
7-14
Topology Does Not Appear
Topology Does Not Appear
The OSM or TSM Low-Level Link is unable to report the topology value. You might get
this result during Step 2.1 Record Basic Information on page 4-4 or Step 2.2 Record
Information About the Master Service Processor on page 6-6.
Cause
The topology value continues to display as Retrieving Data.
Recovery
While still in the OSM or TSM Low-Level Link, from the Display menu, select Refresh.
Unable to Log On to OSM or TSM Low-Level Link
See Code 316 Returned During Logon on page 7-12.
