Troubleshooting
HP NonStop S-Series System Expansion and Reduction Guide—522465-009
7-16
Storage Subsystem Event Messages
Storage Subsystem Event Messages
The symbolic name of each of these events begins with ZSTO-EVT:
Event
Number Name (ZSTO-EVT) Description (page 1 of 2)
1026 -ADAPTER-AUTO-FAILED Autoconfiguration of an adapter failed.
This event is usually preceded by storage
subsystem event 1025 (failed to access
$ZCNF).
1027 -ADAPTER-AUTO-RETRY Waiting for a resource that is blocking auto-
configuration of an adapter.
1028 -CRU-INSERTED Hardware insertion event sent from the
configuration utility process ($ZCNF).
1029 -CRU-REMOVED Hardware deletion event sent from the
configuration utility process ($ZCNF).
1030 -WRONG-CRU-INSERTED Hardware insertion event received does not
match the configuration information in the
system configuration database.
1031 -CRU-CONFIGURED CRU configuration successfully added to the
system configuration database.
1032 -CRU-INIT CRU initialization succeeded.
1033 -CRU-INIT-FAILED CRU initialization failed.
The event contains the error number
returned from the support function used. This
function is offered by the SCSI Interface
Module (SIFM) or by Extensible I/O (XIO).
1034 -POST-COMPLETE Power-on self-test of CRU succeeded.
1035 -POST-FAILED Power-on self-test of CRU failed.
1037 -INVALID-CRU Not enough information available to
determine:
•
What type of CRU was inserted
•
How to configure that CRU
1040 -UNSUPPORTED-CRU CRU inserted that is not supported by the
storage subsystem.
1041 -CRU-OWNERSHIP CRU cannot be configured by the storage
subsystem. The slot where the CRU was
inserted is already configured by another
subsystem.
1042 -CRU-DELETED CRU configuration deleted from the system
configuration database.
