HP NonStop S-Series System Expansion and Reduction Guide—522465-009
A-1
A Common System Operations
This appendix describes how to perform common operations involved in resizing your
system.
Procedure Page
Determine the Processor Type
A-2
Determine the Processor Type Using the OSM or TSM Low-Level Link A-2
Determine the Processor Type Using the OSM Service Connection or TSM
Service Application
A-3
Determine the ServerNet Fabric Status A-4
Check the ServerNet Fabric Status Using the OSM Service Connection or TSM
Service Application
A-4
Check ServerNet Fabric Status Using SCF (Processor Enclosures Only) A-5
Determine the Product Versions of the OSM Client Software A-7
Determine the Product Version of the TSM Client Software A-7
Move the System Console A-8
Stop the OSM or TSM Low-Level Link A-8
Start a Startup TACL Session A-9
Start the OSM or TSM Low-Level Link A-9
Start the OSM Service Connection or TSM Service Application A-9
