Common System Operations
HP NonStop S-Series System Expansion and Reduction Guide—522465-009
A-3
Determine the Processor Type Using the OSM
Service Connection or TSM Service Application
Determine the Processor Type Using the OSM Service
Connection or TSM Service Application
Step Action Result
1.
•
In OSM, select Start>
Programs>HP OSM>OSM Service
Connection.
•
In TSM, select Start>
Programs>Compaq TSM>TSM
Service Application.
2. Log on to the OSM Service Connection
or TSM Service Application.
3. From the tree pane:
a. Double-click the group number
for the enclosure.
b. Double-click one of the PMF
CRUs.
c. Select one of the processors.
The attributes for that processor are
displayed in the Attributes tab.
4. From the Details pane, select the
Attributes tab.
5. From the Attributes tab, check the
processor name to determine the
processor type.
6. To determine the system model number
for this processor type, see the OSM or
TSM online help or the NonStop S-
Series Planning and Configuration
Guide.
7. For the other processor in the enclosure,
repeat Steps 3b through 6.
