Check ServerNet Fabric Status Using SCF
(Processor Enclosures Only)
Check ServerNet Fabric Status Using SCF (Processor
Enclosures Only)
The following example shows how to use the SCF STATUS SERVERNET $ZSNET
command to check the ServerNet communications among processors and provide an
example of the display that might result. This command shows whether two processors
can communicate over a specific fabric.
If the display shows any down paths, see ServerNet Fabrics Are Down on page 7-11.
This SCF command generates listings for the maximum number of processors that are
possible in your system, whether or not the system actually contains the maximum
number of processors. Ensure that the status for all processors actually in your system
is listed as UP.
In this example, processors 0 and 1 cannot communicate with processors 2 and 3 over
the Y fabric. Their listings, which indicate a problem, are highlighted in bold type.
Note. Run this ServerNet path test only if the state of the fabric is in question. The OSM and
TSM package is designed to keep an up-to-date view of the state of the fabric.
