Common System Operations
HP NonStop S-Series System Expansion and Reduction Guide—522465-009
A-7
Determine the Product Versions of the OSM Client
Software
Determine the Product Versions of the OSM
Client Software
To determine the version of the OSM Low-Level Link:
To determine the version of the OSM Notification Director:
Determine the Product Version of the TSM
Client Software
Before you perform this operation, be sure that either the TSM Low-Level Link or the
TSM Service Application is running.
Step Action Result
1. Select Start>Programs>HP OSM
and start OSM Low-Level Link.
The OSM Low-Level Link logon dialog box
appears.
2. Either log on or close the logon
dialog box.
3. From the Help menu, Select About
HP OSM.
The product version of the OSM Low-Level
Link appears.
4. Click Close. The About OSM window disappears.
Step Action Result
1. Select Start>Programs>HP OSM
and start OSM Notification Director.
The OSM Notification Director window
appears.
2. From the Help menu, Select About
HP OSM Notification Director.
The product version of the OSM Notification
Director appears.
Step Action Result
1. In TSM, from the menu bar, click
Help.
A menu appears.
2. Select About TSM. The product version of the TSM client
software is listed.
3. Click Close. The About TSM window disappears.
