HP NonStop S-Series System Expansion and Reduction Guide—522465-009
B-1
B ServerNet Cabling
This appendix shows diagrams of all ServerNet cable connections. It also includes
examples of how you can map these diagrams to actual NonStop S-series enclosures.
Example Includes …
Correlation Between Cabling
Diagram and One Enclosure with
SEBS
•
A sample ServerNet cabling diagram of one
enclosure with connections shown to a SEB
•
The service side of a processor enclosure
•
How the diagram relates to the components in the
enclosure
•
Table B-1, Router Port Connections to SEBs
Correlation Between Cabling
Diagram and One Enclosure with
MSEBS
•
A sample ServerNet cabling diagram of one
enclosure with connections shown to an MSEB
•
The service side of a processor enclosure
•
How the diagram relates to the components in the
enclosure
•
Table B-2, Router Port Connections to MSEBs
Correlation Between Cabling
Diagram and Two Enclosures
•
A sample ServerNet cabling diagram of two
connected enclosures
•
A processor enclosure connected to a NonStop
S-series I/O enclosure
•
How the diagram relates to the components in each
enclosure and the connections between them
Cabling Diagram
NonStop S-Series System — Tetra 8 Topology, X Fabric
NonStop S-Series System — Tetra 8 Topology, Y Fabric
NonStop S-Series System — Tetra 16 Topology, X Fabric
NonStop S-Series System — Tetra 16 Topology, Y Fabric
Note. The Tetra 16 cabling diagrams show the maximum possible number of I/O enclosures.
Your service provider can tell you the number of I/O enclosures supported by the RVU running
on your system.
Note. The diagrams in this guide identify all ServerNet expansion boards as SEBs. Your
system might instead have or require modular ServerNet expansion boards (MSEBs) in the
slots designated for SEBs. SEBs and MSEBs are functionally equivalent.
Caution. ServerNet cabling for IOAM enclosures is different from the cabling shown in this
Appendix. Only service providers trained by HP should perform cabling of IOAM enclosures.
