Checklist: Tools and Supplies
Short Phillips screwdriver
VST206.vsd
NonStop
S-series
TM
system console
Pointed object such as a
straightened metal paper clip
Flashlight
Safety glasses
Antistatic mat
3/4” or 9/16” open-end wrench
3/16” hex socket driver
Small slotted screwdriver
System Console
Installer CD-ROM
NonStop
S-series
TM
Three (3) Ethernet cables
One or more
system enclosures
NonStop
S-series
TM
Ethernet hub
SEBs, MSEBs, adapters,
and other components
you will need for your
resized system
Scissors or cutter
Tape
