Prepare and Stop an E4SA
Prepare and Stop an E4SA
The next examples show how to stop an Ethernet 4 ServerNet adapter (E4SA). These
examples:
•
Use SCF unless otherwise noted
•
Show part of the removal of group 02 from system \TROLL
•
Show an E4SA that was configured to use only Expand-over-IP.
•
Are only examples and might not be appropriate for your system
This example screen shows all associations of Physical Interface (PIF) E4SA02A* to
Logical Interface (LIF) LAN02* in the entire system. The LIF of the E4SA used in this
example appears in boldface.
This example screen shows in boldface the TCP/IP process that corresponds to the
LIF LAN020A.
Note. Other subsystems besides Expand-Over-IP that an E4SA can use are SNAX over
Ethernet, Port Access Method (PAM), and IPX/SPX.
-> INFO LIF $ZZLAN.*
SLSA Info LIF
Name PIF MAC Address Type
$ZZLAN.LAN020A E4SA02A.0.A 08:00:8E:00:CF:5F Ethernet
$ZZLAN.LAN020B E4SA02A.0.B 08:00:8E:00:CF:60 Ethernet
$ZZLAN.LAN021A E4SA02A.1.A 08:00:8E:00:CF:61 Ethernet
$ZZLAN.LAN021B E4SA02A.1.B 08:00:8E:00:CF:62 Ethernet
$ZZLAN.LANX MIOE0.0.A 08:00:8E:00:E3:77 Ethernet
$ZZLAN.LANY MIOE1.0.A 08:00:8E:00:E3:79 Ethernet
-> LISTOPENS LIF $ZZLAN.LAN020A
SLSA Status LIF \TROLL.$ZZLAN.LAN020A
Openers PPID BPID Format Filter
$ZTC20 ( 2,300) ( 3,296) Ethernet $ZTC20.#SN1.BR0
$ZTC20 ( 2,300) ( 3,296) Ethernet $ZTC20.#SN1.MC2
$ZTC20 ( 2,300) ( 3,296) Ethernet $ZTC20.#SN1.IP0
$ZTC20 ( 2,300) ( 3,296) Ethernet $ZTC20.#SN1.AR0
