Stopping Devices and Processes
HP NonStop S-Series System Expansion and Reduction Guide—522465-009
D-8
Stop the E4SA Adapter
This example screen shows the TACL commands you can use to trace processes
started from a TCP/IP session. The processes highlighted in bold type might be
affected by the removal of this E4SA.
The previous five example screens show one session on one LIF on one E4SA.
On this LIF, a number of processes are affected when you stop the E4SA. Each of the
following processes might need to be moved or stopped before you continue with the
system reduction procedure:
•
Processes that access the LIF through the following subsystems: Expand-Over-IP,
PAM, SNAX over Ethernet, and IPX/SPX
•
Direct openers of these same subsystems
•
Clients of those direct openers
Determining this and similar information on any system is highly system-specific. Your
procedures for determining critical processes in the enclosure you will remove might
vary. Consult your system analyst.
Stop the E4SA Adapter
After you have identified the processes that need to be moved or stopped, enter the
appropriate SCF commands to stop the E4SA adapter, its LIF, and the TCP/IP process.
Depending on the subsystem, use the STOP command first, followed by the ABORT
command if necessary.
In this example, the SCF STOP command performs an orderly shutdown of processes:
1-> STOP LIF $ZZLAN.LAN02*
2-> STOP ADAPTER $ZZLAN.E4SA02A, SUB ALL
3-> STOP PROCESS $ZTC20
If a process is still running when you try to stop it, SCF can return a message like:
SLSA E00012 Object $ZZLAN.LAN21 has registered client(s) and
cannot stop.
If all components have not been stopped and you have determined that they can be
forcibly stopped, use the ABORT command:
1-> ABORT LIF $ZZLAN.LAN02*
2-> ABORT ADAPTER $ZZLAN.E4SA02A, SUB ALL
3-> ABORT PROCESS $ZTC20
TACL> STATUS *, TERM $ZTN20.#PTCZA3G
Process Pri PFR %WT Userid Program file Hometerm
$Z02F 7,20 169 005 255,255 SYSTEM.SYS00.TACL $ZTN20.#PTCZA3G
Process Pri PFR %WT Userid Program file Hometerm
$Z02F 6,45 168 P 000 255,255 SYSTEM.SYS00.FUP $ZTN20.#PTCZA3Y
