Stopping Devices and Processes
HP NonStop S-Series System Expansion and Reduction Guide—522465-009
D-9
Delete the E4SA Adapter
Delete the E4SA Adapter
You can use these SCF commands to delete the #E4SA20A adapter along with its
associated LIFs, PIFs, and SACs from the system configuration.
From the OSM Service Connection or TSM Service Application tree pane, the icon of
every device that has been deleted should be yellow, and the Attributes tab should
show the device as Not Configured.
5-> DELETE LIF $ZZLAN.LAN020A
6-> DELETE LIF $ZZLAN.LAN020B
7-> DELETE LIF $ZZLAN.LAN021A
8-> DELETE LIF $ZZLAN.LAN021B
9-> DELETE ADAPTER $ZZLAN.E4SA02A, SUB ALL
