HP NonStop S-Series System Expansion and Reduction Guide—522465-009
1-1
1 The Resizing Process
This section gives background information necessary to understand system resizing.
Definition
System resizing is the process of doing either of the following to a NonStop S-series
system:
•
Expanding the system by adding enclosures
•
Reducing the system by removing enclosures
Topic Page
Definition
1-1
Prerequisites 1-2
Expansion With IOAM Enclosures 1-2
Planning for Resizing 1-3
Does Your System Have Enough MSEBs and MSEB PICs? 1-3
Should You Install a New RVU? 1-4
Topology 1-5
Impact on Users 1-6
System Availability 1-6
System Configuration 1-7
Operations 1-7
Moving a System Console 1-7
Site Planning 1-8
Cabling 1-8
Other Issues 1-9
