NonStop S-Series System Expansion and Reduction Guide
Table Of Contents
- NonStop S-Series System Expansion and Reduction Guide
- What’s New in This Guide
- About This Guide
- 1 The Resizing Process
- 2 Planning System Expansion
- 3 Planning System Reduction
- 4 Reducing a System Online
- 1.Prepare the Donor System for Reduction
- 2.Record Information About the Donor System
- 3.Prepare Both ServerNet Fabrics
- 4.Inventory Enclosures to Be Removed
- 5.Prepare and Stop Devices and Processes
- 6.Ensure Devices and Processes Are Stopped
- 7.Delete Devices and Processes If Necessary
- 8.Prepare Enclosures for Removal
- 9.Finish the Reduction
- 10.Remove Other Cables From Powered-Off Enclosures
- 11.Physically Remove Enclosures From the System
- Adding Enclosures to Another System
- 5 Reducing a System Offline
- 6 Expanding a System Online
- Preparation for Online Expansion
- 1.Prepare Target System for Expansion
- 2.Record Information About Target System
- 3.Prepare Target System for Addition of Block
- 4.Save Current Target System Configuration
- 5.Copy SP Firmware File From the Target System to the System Console
- 6.Finish Gathering Information
- 7.Connect a System Console to the Enclosure
- 8.Change Group Number of Enclosure to 01
- 9.Power On Enclosure
- 10.Verify Connection Between System Console and Enclosure
- 11.Configure System Console and Enclosure
- 12.Verify SP Firmware Is Compatible
- 13.Update SP Firmware in Enclosure If Necessary
- 14.Configure Topology of Enclosure If Necessary
- 15.Power Off Enclosure
- 16.Repeat Steps 6 Through 15 If Necessary
- 17.Assemble Enclosures Into a Block
- 18.Change Group Numbers of Block to Fit Target System
- 19.Disconnect System Console From Block
- 20.Power On Added Block
- 21.Cable Block to Target System
- 22.Verify Resized Target System
- 23a.Update Firmware and Code in Block (Using TSM)
- 23b.Update Firmware and Code in Block (Using OSM)
- 24.Reload Processors in Block If Necessary
- 25.Verify Operations in Added Block
- 26.Configure CRUs in Added Block
- 7 Troubleshooting
- A Common System Operations
- Determine the Processor Type
- Determine the ServerNet Fabric Status
- Determine the Product Versions of the OSM Client Software
- Determine the Product Version of the TSM Client Software
- Move the System Console
- Stop the OSM or TSM Low-Level Link
- Start a Startup TACL Session
- Start the OSM or TSM Low-Level Link
- Start the OSM Service Connection or TSM Service Application
- B ServerNet Cabling
- C Checklists and Worksheets
- D Stopping Devices and Processes
- Safety and Compliance
- Glossary
- Index
G-Series Common Glossary
Glossary-1
Glossary
3-phase. Describes a single power source with three output phases (A, B, and C). The
phase difference between any two of the three phases or currents is 120 degrees.
3860 ATM 3 ServerNet adapter (ATM3SA). See ATM 3 ServerNet adapter (ATM3SA).
3861 Ethernet 4 ServerNet adapter (E4SA). See Ethernet 4 ServerNet adapter (E4SA).
3862 Token-Ring ServerNet adapter (TRSA). See Token-Ring ServerNet adapter (TRSA).
3863 Fast Ethernet ServerNet adapter (FESA). See Fast Ethernet ServerNet adapter
(FESA).
3865 Gigabit Ethernet ServerNet adapter (GESA). See Gigabit Ethernet ServerNet
adapter (GESA).
4619 disk drive. An 18-gigabyte, 15,000-rpm, small computer system interface (SCSI) disk
drive for HP NonStop™ S-series servers running G06.06 and later release version
updates (RVUs). The 4619 disk drive can coexist and operate with lower-capacity or
lower-speed drives in the same storage subsystem module.
4637 disk drive. A 36-gigabyte, 10,000-rpm, small computer system interface (SCSI) disk
drive for HP NonStop™ S-series servers running G06.06 and later release version
updates (RVUs).
6740 ServerNet/FX adapter. See ServerNet/FX adapter.
6742 ServerNet/FX 2 adapter. See ServerNet/FX 2 adapter.
6760 ServerNet device adapter (ServerNet/DA). See ServerNet device adapter
(ServerNet/DA).
6761 F-PIC. See fiber-optic plug-in card (F-PIC).
6762 S-PIC. See SCSI plug-in card (S-PIC).
6763 Common Communication ServerNet adapter (CCSA). See Common
Communication ServerNet adapter (CCSA).
A. See ampere (A).
A0CINFO file. A distribution subvolume (DSV) file that contains information about a product
and each of its files, including product and file dependencies, how the files are used
and where they are placed, and which type of processor the product runs on. Every
product and software product revision (SPR) to be managed by Distributed Systems
Management/Software Configuration Manager (DSM/SCM) is distributed in a
subvolume, and that subvolume must contain the product’s A0CINFO file.
