NonStop S-Series System Expansion and Reduction Guide
Table Of Contents
- NonStop S-Series System Expansion and Reduction Guide
- What’s New in This Guide
- About This Guide
- 1 The Resizing Process
- 2 Planning System Expansion
- 3 Planning System Reduction
- 4 Reducing a System Online
- 1.Prepare the Donor System for Reduction
- 2.Record Information About the Donor System
- 3.Prepare Both ServerNet Fabrics
- 4.Inventory Enclosures to Be Removed
- 5.Prepare and Stop Devices and Processes
- 6.Ensure Devices and Processes Are Stopped
- 7.Delete Devices and Processes If Necessary
- 8.Prepare Enclosures for Removal
- 9.Finish the Reduction
- 10.Remove Other Cables From Powered-Off Enclosures
- 11.Physically Remove Enclosures From the System
- Adding Enclosures to Another System
- 5 Reducing a System Offline
- 6 Expanding a System Online
- Preparation for Online Expansion
- 1.Prepare Target System for Expansion
- 2.Record Information About Target System
- 3.Prepare Target System for Addition of Block
- 4.Save Current Target System Configuration
- 5.Copy SP Firmware File From the Target System to the System Console
- 6.Finish Gathering Information
- 7.Connect a System Console to the Enclosure
- 8.Change Group Number of Enclosure to 01
- 9.Power On Enclosure
- 10.Verify Connection Between System Console and Enclosure
- 11.Configure System Console and Enclosure
- 12.Verify SP Firmware Is Compatible
- 13.Update SP Firmware in Enclosure If Necessary
- 14.Configure Topology of Enclosure If Necessary
- 15.Power Off Enclosure
- 16.Repeat Steps 6 Through 15 If Necessary
- 17.Assemble Enclosures Into a Block
- 18.Change Group Numbers of Block to Fit Target System
- 19.Disconnect System Console From Block
- 20.Power On Added Block
- 21.Cable Block to Target System
- 22.Verify Resized Target System
- 23a.Update Firmware and Code in Block (Using TSM)
- 23b.Update Firmware and Code in Block (Using OSM)
- 24.Reload Processors in Block If Necessary
- 25.Verify Operations in Added Block
- 26.Configure CRUs in Added Block
- 7 Troubleshooting
- A Common System Operations
- Determine the Processor Type
- Determine the ServerNet Fabric Status
- Determine the Product Versions of the OSM Client Software
- Determine the Product Version of the TSM Client Software
- Move the System Console
- Stop the OSM or TSM Low-Level Link
- Start a Startup TACL Session
- Start the OSM or TSM Low-Level Link
- Start the OSM Service Connection or TSM Service Application
- B ServerNet Cabling
- C Checklists and Worksheets
- D Stopping Devices and Processes
- Safety and Compliance
- Glossary
- Index
Glossary
G-Series Common Glossary
Glossary-3
ADAPTER object type
types of cable that can connect any of the six 50-pin WAN ports to one of the
supported electrical interfaces (RS-232, RS-449, X.21, or V.35).
ADAPTER object type. The Subsystem Control Facility (SCF) object type for all adapters
attached to your system.
address space. The memory locations to which a process has access.
ADE. See application development environment (ADE).
adjacent SP. A service processor (SP) that is directly connected through the ServerNet
fabrics to the enclosure of a specified SP.
administrator. (1) For an HP NonStop™ system, the person responsible for the installation
and configuration of a software subsystem on a NonStop node. Contrast with operator
.
(2) For an IBM system, the person responsible for the day-to-day monitoring and
maintenance tasks associated with a software subsystem on an IBM node. (3) For a
UNIX system, the owner of
/dev/console. The administrator is responsible for the
installation and configuration of all hardware and software within a node.
ADP. See Automated Data Processing (ADP).
ALLPROCESSORS paragraph. A required paragraph in the CONFTEXT configuration file
that contains attributes defining the HP NonStop™ Kernel operating system image for
all system processors. The ALLPROCESSORS paragraph follows the optional
DEFINES paragraph.
alternate path. A path not enabled as the preferred path. An alternate path can become a
primary path
when a primary path is disabled.
alternating current (AC). An electric current having a waveform that regularly reverses in
positive and negative directions. North American electrical power alternates 60
times/second (60 hertz). Contrast with direct current (DC)
.
amperage. Current-carrying capacity, expressed in amperes.
ampere (A). The unit of electrical current or rate of flow of electrons. One volt across one
ohm of resistance causes a current flow of one ampere. A flow of one coulomb/second
equals one ampere.
ANSI. The American National Standards Institute.
APE. See Application Program Examiner (APE).
API. See application program interface (API).
appearance side. The side of a system enclosure that contains, behind a door, disk
customer-replaceable units (CRUs) and power monitor and control unit (PMCU) CRUs.
