NonStop S-Series System Expansion and Reduction Guide
Table Of Contents
- NonStop S-Series System Expansion and Reduction Guide
- What’s New in This Guide
- About This Guide
- 1 The Resizing Process
- 2 Planning System Expansion
- 3 Planning System Reduction
- 4 Reducing a System Online
- 1.Prepare the Donor System for Reduction
- 2.Record Information About the Donor System
- 3.Prepare Both ServerNet Fabrics
- 4.Inventory Enclosures to Be Removed
- 5.Prepare and Stop Devices and Processes
- 6.Ensure Devices and Processes Are Stopped
- 7.Delete Devices and Processes If Necessary
- 8.Prepare Enclosures for Removal
- 9.Finish the Reduction
- 10.Remove Other Cables From Powered-Off Enclosures
- 11.Physically Remove Enclosures From the System
- Adding Enclosures to Another System
- 5 Reducing a System Offline
- 6 Expanding a System Online
- Preparation for Online Expansion
- 1.Prepare Target System for Expansion
- 2.Record Information About Target System
- 3.Prepare Target System for Addition of Block
- 4.Save Current Target System Configuration
- 5.Copy SP Firmware File From the Target System to the System Console
- 6.Finish Gathering Information
- 7.Connect a System Console to the Enclosure
- 8.Change Group Number of Enclosure to 01
- 9.Power On Enclosure
- 10.Verify Connection Between System Console and Enclosure
- 11.Configure System Console and Enclosure
- 12.Verify SP Firmware Is Compatible
- 13.Update SP Firmware in Enclosure If Necessary
- 14.Configure Topology of Enclosure If Necessary
- 15.Power Off Enclosure
- 16.Repeat Steps 6 Through 15 If Necessary
- 17.Assemble Enclosures Into a Block
- 18.Change Group Numbers of Block to Fit Target System
- 19.Disconnect System Console From Block
- 20.Power On Added Block
- 21.Cable Block to Target System
- 22.Verify Resized Target System
- 23a.Update Firmware and Code in Block (Using TSM)
- 23b.Update Firmware and Code in Block (Using OSM)
- 24.Reload Processors in Block If Necessary
- 25.Verify Operations in Added Block
- 26.Configure CRUs in Added Block
- 7 Troubleshooting
- A Common System Operations
- Determine the Processor Type
- Determine the ServerNet Fabric Status
- Determine the Product Versions of the OSM Client Software
- Determine the Product Version of the TSM Client Software
- Move the System Console
- Stop the OSM or TSM Low-Level Link
- Start a Startup TACL Session
- Start the OSM or TSM Low-Level Link
- Start the OSM Service Connection or TSM Service Application
- B ServerNet Cabling
- C Checklists and Worksheets
- D Stopping Devices and Processes
- Safety and Compliance
- Glossary
- Index
Glossary
G-Series Common Glossary
Glossary-15
communications line
communications line. A two-way link consisting of processing equipment, I/O devices,
protocol conventions, and cables that connect a computer to other computers.
communications line interface processor (CLIP). The major programmable device within
the ServerNet wide area network (SWAN) concentrator, providing link-level protocol
and a software interface to the host. The CLIP stores and implements specific
communications protocols.
Communications Management Interface (CMI). A utility used in D-series and earlier
release version updates (RVUs) to make online changes to the configuration of
ATP6100, CP6100, and EnvoyACP/XF communications subdevices. In G-series
RVUs, CMI functions are performed by the Subsystem Control Facility (SCF).
communications subsystem. The combination of data communications hardware and
software processes that function together as an integrated unit to provide services and
access to wide and local area networks.
Compaq TSM. Identifies a client or server software component used to manage or service
HP NonStop™ S-series servers. See also Compaq TSM client software
and Compaq
TSM server software.
Compaq TSM client software. The component of the Compaq TSM package that runs on a
system console. The TSM client software consists of the TSM Low-Level Link, the
TSM Service Application, the TSM Notification Director, and the TSM Event Viewer.
See also Compaq TSM server software
.
Compaq TSM Event Viewer. A component of the Compaq TSM client software. The TSM
Event Viewer lets you set up criteria to view Event Management Service (EMS) log
files in several ways, enabling you to rapidly assess service problems.
Compaq TSM Low-Level Link. A component of the Compaq TSM client software. The
TSM Low-Level Link enables you to communicate with an HP NonStop™ S-series
server even when the HP NonStop Kernel operating system is not running. When the
operating system is running, you usually communicate with the server using the TSM
Service Application. See also Compaq TSM Service Application
.
Compaq TSM package. A software product for HP NonStop™ S-series servers that
provides the information needed to perform functions such as querying resources and
testing, provides notification of problems on the system, and allows local or remote
access to the system for service and maintenance. The TSM package performs the
same role as that of HP Tandem Maintenance and Diagnostic System (TMDS),
Syshealth, and Remote Maintenance Interface (RMI) on earlier systems.
Compaq TSM server software. The component of the Compaq TSM package that runs on
an HP NonStop™ S-series server. When the HP NonStop Kernel operating system is
running, the TSM client software on a system console communicates with a server
through the TSM server software. See also Compaq TSM client software
.
