Glossary
G-Series Common Glossary
Glossary-51
Internet control message protocol (ICMP)
physical network, an Internet address consists of a network portion and a host portion.
See also IP address
.
Internet control message protocol (ICMP). A maintenance protocol in the Transmission
Control Protocol/Internet Protocol (TCP/IP) suite that is required in every TCP/IP
implementation. The ICMP allows two nodes on an IP network to share IP status and
error information. The ICMP is used by the ping utility to determine the readability of a
remote system. See also IP address
and ping.
Internet protocol (IP). A data communications protocol that handles the routing of data
through a network, which typically consists of many different subnetworks. IP is
connectionless. It routes data from a source address to a destination address. See
also IP address
.
interoperability. (1) Within an HP NonStop™ node, the ability to use the features or
facilities of one environment from another. For example, the
gtacl command in the
Open System Services (OSS) environment allows an interactive user to start and use a
Guardian tool in the Guardian environment. (2) Among systems from multiple vendors
or with multiple versions of operating systems from the same vendor, the ability to
exchange status, files, and other information. Product externals and end-user
publications for the NonStop range of servers often use the term
connectivity in this
context. See also connectivity
.
interprocessor communications (IPC). The exchange of messages between processors.
intrinsic library. See Shared Millicode Library.
instance. A particular case of a class of items or objects. For example, a process is defined
as one instance of the execution of a program. Multiple processes might be executing
the same program simultaneously. Also, instance data refers to global data of a
program or library. Each process has its own instance of the data.
instance data. For each process using a dynamic-link library, a data segment area
containing the global variables used by the library.
I/O adapter module (IOAM). A collection of modular components that provides I/O
connectivity and can include ServerNet switch boards, Fibre Channel ServerNet
adapters (FCSAs), fans, and power supplies. In the IOAM, each module is a logical
entity that represents a single service domain.
I/O adapter module enclosure (IOAM enclosure). The sheet-metal carrier that is installed
in a standard 19-inch rack and contains the IOAM components.
IOAM. See I/O adapter module (IOAM).
IOAM enclosure. See I/O adapter module enclosure (IOAM enclosure).
I/O cabinet. See I/O enclosure.
