HP NonStop S-Series System Expansion and Reduction Guide—522465-009
2-1
2 Planning System Expansion
This section defines the concept of blocks and describes how to use the worksheets in
this guide to plan the orderly addition of enclosures.
About Blocks
When you expand your system online, you add enclosures in a group that is called a
block.
Definition
A block is a group of one or more system enclosures that is supported and recognized
as a unit by your system.
Whether a block is a single enclosure or multiple enclosures, it must have a properly
balanced distribution of hardware and software for the topology of the system to which
it will be added.
Examples
These units are blocks:
•
One processor enclosure
•
One I/O enclosure (or one IOAM enclosure)
•
One processor enclosure with one or more I/O enclosures attached
In contrast, these units are not blocks:
•
Two or more processor enclosures cabled together. This unit is not a block
because each processor enclosure is a block by itself.
Topic Page
About Blocks
2-1
Definition 2-1
Examples 2-1
Rules for Creating a Block 2-2
Block Structures 2-2
Supported Block Structures 2-3
Examples of Block Structures 2-4
Choosing Which Block Structure to Use 2-8
Example of Choosing a Block Structure 2-8
Enclosures From Another System 2-14
