Glossary
G-Series Common Glossary
Glossary-95
service equipment
server. A service connection can be used to communicate with the server only when
the HP NonStop™ Kernel operating system is running. A service connection provides
a comprehensive service and maintenance picture of the server and is used to perform
most service management tasks. See also low-level link
.
service equipment. The necessary equipment, usually consisting of circuit breakers and
their accessories, that is located near the entrance point of supply conductors. This
equipment constitutes the main control and cutoff means of the supply.
service processor (SP). A physical component of the processor multifunction (PMF)
customer-replaceable unit (CRU) or I/O multifunction (IOMF) CRU that controls
environmental and maintenance functions (including system load functions) in the
enclosure. SPs operate in pairs to provide fault tolerance. The two SPs in group 01 are
designated the master service processors (MSPs). Other pairs of SPs within a system
are called expansion service processors (ESPs). See also expansion service
processor (ESP) and master service processor (MSP).
service provider. (1) A person trained and qualified to service field-replaceable units
(FRUs). (2) An organization, such as the Global Customer Support Center (GCSC),
that helps you resolve problems with your HP NonStop™ S-series server. OSM and
TSM allow you to use the help of a service provider by configuring client software to
support remote notification and remote access.
service side. The side of a system enclosure that contains, behind an optional door,
processor multifunction (PMF) customer-replaceable units (CRUs) or I/O multifunction
(IOMF) CRUs, ServerNet expansion boards (SEBs), modular SEBs (MSEBs), and
ServerNet adapters. The service side is opposite the appearance side
. Cables are
accessed from the service side. System enclosures are typically arranged so that the
service side is the least visible side.
session. In the Open System Services (OSS) environment, a set of process groups
associated for job control purposes. A session can have a controlling terminal.
session leader. In the Open System Services (OSS) environment, the process that created
a session.
session lifetime. In the Open System Services (OSS) environment, the period that begins
when a session is created and ends when the lifetime of the last remaining process
group of the session ends.
setup configuration. A simple stand-alone network used to configure the OSM or TSM
environment. The setup configuration consists of the server, the primary system
console, an Ethernet hub, and two local area network (LAN) cables. One cable
connects the primary system console to the hub, and another cable connects the hub
to a processor multifunction (PMF) customer-replaceable unit (CRU) in group 01 of the
server. When OSM or TSM configuration is complete, the setup configuration can
serve as the working network configuration. Variations of the setup configuration can
be constructed using additional cables and hubs to increase fault tolerance.
