Glossary
G-Series Common Glossary
Glossary-115
user ID
user ID. The unique identification of a user within a node.
In the Guardian environment, the term
user ID usually means the structured view of the
HP NonStop™ Kernel user ID
. In the Open System Services (OSS) environment, the
term
user ID usually means the scalar view of the HP NonStop™ Kernel user ID—a
number called the UID
.
User Library (UL). See TNS code space.
user library. A logically distinct part of the HP NonStop™ Kernel operating system that
consists of procedures that the operating system can link to a program file at run time.
user name. A string that uniquely identifies a user within the user database for a node.
UTC. See Coordinated Universal Time (UTC).
UTP. See unshielded twisted pair (UTP).
V. See volt (V).
V.35. The International Telecommunications Union, Telecommunication Standardization
Sector (ITU-T) standard for data transmission at 48 kilobits/second over 60 - 108
kilohertz group band circuits. It contains the 34-pin V.34 connector specifications
normally implemented on a modular RJ-45 connector. V.35 is the equivalent of
Electronics Industry Association (EIA) RS-422/RS-449.
V AC. Volts of alternating current.
vertical tetrahedron. A topology of HP NonStop™ S-series servers in which the ServerNet
connections between the layers of a cluster switch group
form a tetrahedron. See also
tetrahedron
, tetrahedral topology, and cluster switch layer.
virtual file system. In UNIX and Open System Services (OSS), a file system that allows
files of a fileset to be distributed across several physical devices.
volt (V). The standard unit of measure of the potential difference that is required to move an
electric charge.
volume. A logical disk, which can be one or two magnetic disk drives. In HP NonStop™
S-series systems, volumes have names that begin with a dollar sign ($), such as
$DATA. See also mirrored disk or volume
.
WAN. See wide area network (WAN).
WANBoot process. A process provided as part of the wide area network (WAN) subsystem
that implements the BOOTP protocol and provides management functions to the WAN
subsystem and the WAN products.
WAN concentrator. See ServerNet wide area network (SWAN) concentrator and ServerNet
wide area network (SWAN) 2 concentrator.
