Planning System Expansion
HP NonStop S-Series System Expansion and Reduction Guide—522465-009
2-7
Examples of Block Structures
Structure 2
•
One processor enclosure supports one I/O enclosure.This combination becomes
one block.
•
The other processor enclosure supports the other I/O enclosure. This combination
becomes one block.
Figure 2-4 illustrates how four enclosures can become two identical blocks:
Figure 2-4. Four Enclosures as Two Identical Blocks
Processor
Enclosure
Processor
Enclosure
I/O
Enclosure
I/O
Enclosure
0
BlockBlock
2
blocks
4
enclosures
++=
+
VST103.vsd
