Planning System Reduction
HP NonStop S-Series System Expansion and Reduction Guide—522465-009
3-4
Is the Enclosure Providing Critical Resources?
Is the Enclosure Providing Critical Resources?
Information about critical resources is system-specific. Therefore, consult your system
analyst and service provider to determine the actions most appropriate for your
system.
Determine the following information about each enclosure you will remove:
•
What devices, adapters, and processes it contains
•
What communication paths it maintains for other enclosures
You need to know this information so that you can reconfigure your system to maintain
any processes and communication paths that otherwise would be disrupted when
enclosures are removed.
For example:
•
Removing an enclosure that contains Ethernet 4 ServerNet Adapters (E4SAs),
Gigabit Ethernet ServerNet Adapters (GESAs), or Gigabit Ethernet 4-Port
ServerNet Adapters (G4SAs) will disrupt TCP/IP processes that are configured to
use the Ethernet adapters.
•
Removing an enclosure that has Kernel-Managed Swap Facility (KMSF) swap files
on its disks might cause applications or system processes to terminate.
Devices, Adapters, and Processes
Devices, adapters, and processes in the enclosure you plan to remove can be located
by using either the OSM Service Connection or TSM Service Application.
Before you begin the reduction procedure, record this information on the appropriate
worksheets in Appendix C
. Then, with your system analyst, determine critical
operations that should first be moved to other enclosures or terminated.
Indirect Communication Paths
Neither the OSM Service Connection or TSM Service Application displays indirect
paths of communication. However, these indirect paths can affect other enclosures
significantly.
For example: groups 08 and 41 communicate with each other through group 04. Group
41 might connect through group 04 to use a process that is running in group 08.
Therefore, if you remove group 08, group 41 is also affected.
Dependent processes and indirect communication paths can be of three types:
•
Active processes and communication paths using a device
•
Active processes and communication paths not currently using a device
For Information About See
KMSF swap files Kernel-Managed Swap Facility (KMSF) Manual
