Planning System Reduction
HP NonStop S-Series System Expansion and Reduction Guide—522465-009
3-5
Is the Enclosure an IOAM Enclosure?
•
Processes and communication paths not started that might need a device
For more information, see Determining Communication Paths on page 3-6.
Is the Enclosure an IOAM Enclosure?
If you are planning to remove an OAM enclosure from your system, the enclosure must
be removed by a service provider trained by HP. See Expansion With IOAM
Enclosures on page 1-2.
