Planning System Reduction
HP NonStop S-Series System Expansion and Reduction Guide—522465-009
3-8
Example Using the ServerNet Worksheets
2. Highlight Your Present System Configuration
Using a highlighter on a copy of Worksheet 9 or Worksheets 10 and 11, shade in all the
ports, slots, and enclosures your current system contains.
The next example worksheet shows a system that contains the following enclosures:
Processor Enclosure Groups I/O Enclosure Groups
01 11, 12, 13, 14, 15
02 21, 22, 23, 24, 25
03 31, 32, 33, 34, 35
04 41, 42, 43, 44, 45
05 51, 52, 53, 54, 55, 56, 57
06 61, 62, 63, 64, 65, 66
Caution. The connections to IOAM enclosures are different from those shown in the following
topology diagrams. A service provider trained by HP must remove IOAM enclosures from your
system.
