Planning System Reduction
HP NonStop S-Series System Expansion and Reduction Guide—522465-009
3-17
Order of Removal
Order of Removal
After you have prepared your system, power off and remove enclosures starting with
the largest enclosure number. Proceed in decreasing numerical order by enclosure
number, and end with the smallest enclosure number.
For example, if you remove group 02, you affect the associated I/O enclosure groups
21, 22, 23, 24, and 25. You also affect group 06 and its associated I/O enclosure
groups 61, 62, 63, 64, 65, and 66.
Therefore, remove these enclosures from your system one at a time in this order:
66, 65, 64, 63, 62, 61, 25, 24, 23, 22, 21, 06, 02
The Next Step
When you finish planning which enclosures to remove from the donor system, proceed
to Section 4, Reducing a System Online.
Caution. Never remove group 01. Doing so will halt your system.
