Reducing a System Online
HP NonStop S-Series System Expansion and Reduction Guide—522465-009
4-2
1. Prepare the Donor System for Reduction
1. Prepare the Donor System for Reduction
1.1 Prepare Worksheets
1. From Appendix C, make copies of Worksheet 1 and Worksheets 2.1 through 2.8
(referred to hereafter as Worksheets 2.n).
If the system contains any IOAM enclosures, also make copies of Worksheet 2.1a.
2. Circle the words Donor System at the top of each worksheet.
3. Make one copy of Worksheet 8 in Appendix C for each enclosure you will remove.
If any of the enclosures is an IOAM enclosure, make a copy of Worksheet 8a.
4. Staple these worksheets together into a donor system packet.
If you will be adding these enclosures to another (target) system, be sure to keep this
donor packet separate from worksheets for the target system. It is important not to mix
information from your target system with information from your donor system.
1.2 Upgrade OSM or TSM Software If Necessary
OSM Client Software
To determine whether the OSM Client Software components need to be upgraded:
OSM Console Tools
HP recommends that you install the OSM Console Tools to get the most recent versions of the
OSM Service Connection and the OSM Event Viewer. See the NonStop System Console
Installer Guide.
Step Action Use This Procedure
1. Determine the current version of
the OSM Client software
components.
Determine the Product Versions of the OSM
Client Software on page A-7.
2. Determine whether you are running
the latest versions of the client
software.
See
the OSM Migration Guide
3. Upgrade the client software, if
necessary
See the NonStop System Console Installer
Guide.
