Reducing a System Online
HP NonStop S-Series System Expansion and Reduction Guide—522465-009
4-4
2. Record Information About the Donor System
2. Record Information About the Donor System
Before you physically remove enclosures from your donor system, you must record
information about those enclosures on the worksheets in Appendix C. You determine
this information by using a system console.
2.1 Record Basic Information
Continue filling out worksheets for the donor system, as follows:
If you are performing offline system reduction, return to Section 5, Reducing a System
Offline.
Step Action Result
1. On the OSM or TSM Low-Level Link
tool bar, click System Discovery.
After several minutes, the Management
window appears. The Attributes tab
displays the following:
•
System Name
•
System Serial Number
•
System Type
•
Topology
•
SP Firmware Version (on status bar at
bottom of main window)
2. Record this information on Worksheet 1 of the donor system packet.
