Reducing a System Online
HP NonStop S-Series System Expansion and Reduction Guide—522465-009
4-6
2.3 Label Enclosures
2.3 Label Enclosures
You must identify each enclosure you plan to remove before you remove it from the
donor system. Use copies of the completed worksheets as labels:
1. Make a copy of the Worksheets from 2.1 through 2.8 that you filled out for the
donor system packet.
If IOAM enclosures are involved, make a copy of Worksheet 2.1a.
2. To each enclosure you are removing from the donor system, tape a copy of the
worksheet that describes that enclosure.
3. Prepare Both ServerNet Fabrics
To successfully reduce your system online, check that both ServerNet fabrics in your
system are fully operational. If any ServerNet alarms have been generated, you must
eliminate these problems before you can resize your system online.
3.1 Determine Status of ServerNet Fabrics
Use the OSM Service Connection or TSM Service Application and SCF to determine
this status, as described in Determine the ServerNet Fabric Status on page A-4.
3.2 Eliminate Problems in the ServerNet Fabrics
If any ServerNet fabrics are not up, follow the recovery procedure in ServerNet Fabrics
Are Down on page 7-11.
