Reducing a System Online
HP NonStop S-Series System Expansion and Reduction Guide—522465-009
4-12
8.3 Disable ServerNet Ports in Y-fabric MSEBs (or
SEBs)
8.3 Disable ServerNet Ports in Y-fabric MSEBs (or SEBs)
This procedure disables the Y-fabric ServerNet ports in processor enclosures that are
connected to the enclosure you are removing.
Note. Consult the topology diagrams in the planning worksheets to determine which
ServerNet ports need to be disabled. An I/O enclosure is connected to only one port on one
processor enclosure; however, a processor enclosure might be connected to a port on as
many as 4 other processor enclosures.
Step Action Result
1. In the tree pane of OSM or TSM, navigate to a processor
enclosure that is connected to the enclosure you want to
remove. Expand the group and module so you can see the
MSEBs (or SEBs).
2. Right click the Y-fabric MSEB that is connected to the enclosure
you are removing.
Select Actions.
The actions dialog
box appears.
3. Select Disable ServerNet (Router) Port and click Perform
Action.
4. Follow the screen prompts to disable the appropriate ServerNet
port.
5. If you are removing a processor enclosure that is connected to
other processor enclosures, repeat steps 1 through 4 for the
appropriate ServerNet ports on those enclosures.
6. Close the Actions dialog box The tree pane
reappears.
Table 4-1. Router Port Connections to SEBs
Router Port Connects to SEB
1 Cable connector 5
2 Cable connector 4
3 Cable connector 3
4 Cable connector 2
5 Cable connector 1
