Reducing a System Online
HP NonStop S-Series System Expansion and Reduction Guide—522465-009
4-14
8.5 Power Off Enclosure
8.5 Power Off Enclosure
Ensure that all processors in the enclosures to be removed have been prepared and
halted, if applicable, before powering off the enclosures:
Step Action Result
1. From the OSM Service Connection
or TSM Service Application, select
the Display menu. Right-click the
enclosure you want to power off.
A dialog box appears.
2. Select Actions. A dialog box appears.
3. Select Power Off.
4. Select Perform Action.
5. Click OK and then Close. In OSM,
if the battery is not disabled,
another confirmation dialog box
opens. If this happens, click Yes.
In the tree pane, the devices in the
enclosure to be removed disappear. The
icon of the enclosure disappears from the
Management window, indicating that the
enclosure has been powered off.
6. Repeat this procedure for each enclosure to be removed.
Caution. For TSM, if an enclosure does not power off when you perform this procedure, you
can perform a Force Power Off operation. However, the Force Power Off operation might have
severe consequences. Before you perform this operation, consult your system analyst. For
OSM, if an enclosure does not power off when you perform this procedure, contact your
service provider.
Note. You cannot power off an IOAM enclosure from OSM. Under normal circumstances, only
a service provider trained by HP should power off an IOAM enclosure.
