Reducing a System Online
HP NonStop S-Series System Expansion and Reduction Guide—522465-009
4-18
8.9 Verify Enclosures Are Removed From System
Configuration
8.9 Verify Enclosures Are Removed From System Configuration
The icons of the enclosures disappear from the display in the OSM Service Connection
or TSM Service Application, but you need to confirm that the enclosures have been
removed from the system configuration:
8.10 Prepare Any Remaining Enclosures To Be Removed
Repeat steps 8.1 through 8.9 for all enclosures you are removing.
Step Action Result
1. Log off of the OSM or TSM Low-
Level Link Application and then log
back on.
This action synchronizes the OSM Service
Connection or TSM Service Application with
the resized system.
2. From the OSM or TSM Low-Level
Link Application, click System
Discovery.
The Management window appears.
The display might take several minutes to
appear.
3. In the tree pane, double-click the
icon for the system.
All enclosures appear except the removed
enclosures.
If all remaining enclosures with their devices
do not appear after several minutes, see
System Discovery Does Not Show All CRUs
or Enclosures on page 7-13.
