Expanding a System Online
HP NonStop S-Series System Expansion and Reduction Guide—522465-009
6-2
Preparation for Online Expansion
Preparation for Online Expansion
Preparation for online expansion depends on where you get the enclosures with which
you will be expanding your system.
If the enclosures come from another system:
If the enclosures come directly from the factory:
Step For more information
1. Ensure that the system you are expanding
contains an adequate number of MSEBs
and MSEB PICs.
Does Your System Have Enough MSEBs
and MSEB PICs? on page 1-3
2. Plan the procedure of removing enclosures
from another system.
Section 3, Planning System Reduction
3. Remove enclosures from the donor system. Section 4, Reducing a System Online
4. Expand the target system. Perform the procedures in this section.
Step For more information
1. Ensure that the system you are expanding
contains an adequate number of MSEBs
and MSEB PICs.
Does Your System Have Enough MSEBs
and MSEB PICs? on page 1-3
2. Expand your system. Perform the procedures in this section.
