Expanding a System Online
HP NonStop S-Series System Expansion and Reduction Guide—522465-009
6-4
1. Prepare Target System for Expansion
1. Prepare Target System for Expansion
This procedure assumes that both ServerNet fabrics in your system are fully
operational. If any ServerNet alarms have been generated, you must eliminate those
problems before you expand your system online.
Adding blocks must not conflict with the operations of your system. Therefore, you
must prepare both the blocks you are adding and the target system you are expanding.
For... See...
Tools and Supplies
Table 6-1, following
Preparatory Steps
Table 6-2 on page 6-5
Checklists to copy and mark Appendix C, Checklists and Worksheets
Table 6-1. Tools and Supplies
Tool or Supply Used to …
A system console, as described in Step
5.1 Choose System Console to Use
on
page 6-11
Communicate with target system and with
the enclosures you are configuring into a
block
HP NonStop Server System Console
Installer CD
Install the OSM or TSM package on all
system consoles
Ethernet switch or hub and three Ethernet
cables
Connect the system console to the
enclosures you are configuring into a block
One or more NonStop S-series enclosures Expand your system
SEBs or MSEBs Expand your system
Adapters or other components Populate added blocks on your system as
needed
Short Phillips screwdriver Tighten screws on power retainers and
groundstraps
Small slotted screwdriver Tighten screws
3/16-inch hex socket driver Tighten nuts
3/4-inch or 9/16-inch open-end wrench Lower the enclosure legs
Antistatic mat Protect components from electrostatic
discharge
Tape or cable labels Label ServerNet cables and attach
worksheets to enclosures
Scissors or cutter Cut plastic straps on shipping packages
