NonStop S-Series System Expansion and Reduction Guide

Expanding a System Online
HP NonStop S-Series System Expansion and Reduction Guide—522465-009
6-8
2.4 Record Service Connection IP Addresses
2.4 Record Service Connection IP Addresses
Perform this step once for each enclosure in the target system.
Step Action Result
1. In the OSM or TSM Low-Level Link
window, select File.
A menu appears.
2. Select Edit System List …. The Edit Systems List dialog box appears,
containing the name of the target system.
(You might have to scroll down to find it.)
3. Highlight the name of the target system.
4. Click Modify. The Modify System dialog box displays the
following information:
•
Primary Service Connection IP address
•
Backup Service Connection IP address
5. Record these addresses on Worksheet 2.n of the target system packet.
6. Click Cancel. The Modify System dialog box disappears.
7. Click OK. The Edit Systems List dialog box
disappears.
8. Repeat this procedure from Step 1 for every other enclosure in the target system.
