5.2 Identify IP Address for FTP Session
A display such as the following can take a few moments to appear:
3. Note the adapters named \system-name.LANX or \system-name.LANY. Do not
use either of these adapters to copy SP firmware.
4. Ask your network administrator which one of the other adapters should be used to
create a file transfer protocol (FTP) session between the system console and the
target system. In this example, the E4SA device is \TROLL.LAN670A, shown in
boldface. Its IP address of 172.17.116.175 is used in the next step.
->INFO SUBNET $*.*
TCPIP Info SUBNET \TROLL.$ZTC00.*
Name Devicename *IPADDRESS TYPE *SUBNETMASK SuName QIO *R
#LOOP0 \NOSYS.$NOIOP 127.0.0.1 LOOP-BACK %HFF000000 OFF N
#SN1 \TROLL.LAN670A 172.17.116.175 ETHERNET %HFFFFFF00 ON N
TCPIP Info SUBNET \TROLL.$ZTC20.*
Name Devicename *IPADDRESS TYPE *SUBNETMASK SuName QIO *R
#LOOP0 \NOSYS.$NOIOP 127.0.0.1 LOOP-BACK %HFF000000 OFF N
#SN1 \TROLL.LAN020A 172.17.116.190 ETHERNET %HFFFFFF00 ON N
TCPIP Info SUBNET \TROLL.$ZTCP0.*
Name Devicename *IPADDRESS TYPE *SUBNETMASK SuName QIO *R
#LOOP0 \NOSYS.$NOIOP 127.0.0.1 LOOP-BACK %HFF000000 OFF N
#SN1 \TROLL.LANX 172.17.116.173 ETHERNET %HFFFFFF00 ON N
TCPIP Info SUBNET \TROLL.$ZTCP1.*
Name Devicename *IPADDRESS TYPE *SUBNETMASK SuName QIO *R
#LOOP0 \NOSYS.$NOIOP 127.0.0.1 LOOP-BACK %HFF000000 OFF N
#SN1 \TROLL.LANY 172.17.116.174 ETHERNET %HFFFFFF00 ON N
